How Cement Is Made: Quarry, Kiln, Clinker and Grinding
Portland cement is made by heating finely ground limestone and clay until they partly fuse, then grinding the result with a little gypsum. That one sentence hides a lot of careful chemistry, and a few of the steps explain things you notice on site: why cement sets when it does, why some cements gain strength faster, and why a bag left in a damp shed goes lumpy. Here is the process from quarry to bag.
1. Raw materials and quarrying
Cement needs four main elements in the right balance: calcium, silicon, aluminum and iron.
- Calcium comes from limestone (calcium carbonate), chalk or marl, the bulk of the raw feed.
- Silica, alumina and iron come from clay or shale, with small amounts of sand, iron ore or other materials added to correct the chemistry.
Cement plants are usually built next to a limestone quarry. The rock is blasted, loaded and crushed to gravel size near the face.
2. Grinding and blending the raw meal
The crushed materials are proportioned and ground together in a raw mill into a fine powder called raw meal. The plant samples it continuously (usually by X-ray analysis) and adjusts the feed, then blends it in silos so the chemistry entering the kiln is uniform. Small errors here show up as cement that sets or gains strength inconsistently.
Older plants ground the raw materials with water into a slurry (the wet process). Modern plants use the dry process, which needs much less fuel because there is no water to boil off.
3. Preheating and calcining
The raw meal enters a tall preheater tower, where it falls through a series of cyclones against hot gases rising from the kiln. Many plants also have a precalciner, a burner vessel at the base of the tower. Here the limestone breaks down at around 1,650 F (900 C):
calcium carbonate (limestone) + heat = calcium oxide (lime) + carbon dioxide
This step, calcination, releases CO2 from the rock itself, regardless of the fuel used.
4. The rotary kiln and clinker
The hot meal enters a rotary kiln: a long steel tube lined with refractory brick, sloped slightly and turning slowly, with a flame at the lower end. Material moving toward the flame reaches about 2,640 F (1,450 C). At that temperature part of it melts, and the lime combines with silica, alumina and iron to form the four main clinker compounds:
| Compound (cement shorthand) | What it does in concrete |
|---|---|
| Tricalcium silicate (C3S, alite) | Hydrates fairly quickly; most of the early strength, up to about 28 days |
| Dicalcium silicate (C2S, belite) | Hydrates slowly; strength gain after the first weeks |
| Tricalcium aluminate (C3A) | Reacts very fast with water and gives off heat; vulnerable to sulfate attack, so it is limited in Type II and Type V cements |
| Tetracalcium aluminoferrite (C4AF) | Little strength; gives gray cement its color |
The material leaves the kiln as dark gray nodules, typically marble-sized, called clinker. It is cooled quickly in a clinker cooler, and the hot air is reused in the kiln.
5. Finish grinding with gypsum
Clinker is ground in ball mills or vertical roller mills with a few percent of gypsum (calcium sulfate). Without gypsum, the C3A would react almost instantly with water and the cement would stiffen within minutes (a "flash set"). Gypsum slows that reaction and gives you working time.
This is also where cement types are made:
- Type III (high early strength) is ground finer, so more surface reacts sooner.
- Type IL (portland-limestone cement) has 5% to 15% raw limestone ground in with the clinker.
- Blended cements such as Type IP, Type IS, PPC and PSC combine clinker with fly ash, slag or other materials. See types of cement.
6. Testing, storage and shipping
Finished cement is tested for chemistry, fineness, setting time and strength. The standard US strength test (ASTM C109) breaks 2 in (50 mm) cubes of cement-sand mortar at set ages. Cement is stored in silos and shipped in bulk tankers to ready-mix plants, or packed in bags: 94 lb in the US, 50 kg in many other countries.
Where the CO2 comes from
Most of the carbon in concrete comes from making the cement's clinker, from two sources: calcination of limestone (often put at roughly 60% of a plant's CO2) and the fuel that heats the kiln (most of the rest). That is why the main levers for lower-carbon concrete are using less clinker per cubic yard (Type IL, fly ash, slag) and more efficient kilns. See lower-carbon concrete.
What this means when you use cement
- Bags go off because cement reacts with moisture. Clinker minerals start hydrating with humidity in the air, forming hard lumps. Store bags off the floor, covered and away from damp walls. See how to tell if cement has gone off.
- The heat you feel in fresh concrete is hydration. Finer, faster cements give off more heat, which matters in thick pours and hot weather.
- Do not add anything to "speed up" a bag that the maker does not list; the set is controlled by the gypsum balance.
- Handle dry cement as an irritant: open and pour bags with a dust mask and eye protection, standing upwind, and wear alkali-resistant gloves once water is added, because wet cement can cause chemical burns.
